Set up your Brother QL-1110NWB printer

Learn how to turn on your Brother QL-1110NWB printer, and connect it to your network or kiosk (iPad) via Bluetooth.

What is in the box

When you receive the box containing the printer the following items will be included:

• 1 Brother QL-1110NWB printer
• 1 DK roll inserted into the printer
• 1 AC Adapter
• 1 AC cable connector

If any items are missing, contact your customer success representative or the FacilityOS support team.

Turn the printer on

1. Connect the AC adapter to the AC power cord.
2. Connect the AC adapter to the printer.
3. Connect the AC power cord to a grounded AC power outlet.
4. On the printer, press the power button to turn it on. The LED light above the button will turn green.

Connect the printer

You can connect the Brother QL-1110NWB printer to your network or connect it to your iPad via Bluetooth. For the easiest and most reliable experience, we recommend connecting via Bluetooth.

Connect via Bluetooth

1. On the printer, Press and hold the Bluetooth button until the LED light above it turns blue.

2. On the iPad, pair the printer with Bluetooth. For more information, see Apple's article, Pair a Bluetooth accessory.

   Note:

   In the iPad Bluetooth device list, the printer name starts with "QL-1110NWB".

Connect to your network

• To connect via Wi-Fi, see Brother's user's guide Connect Using Wi-Fi.
• To connect via a wired LAN, see Brother's Connect Using a Wired LAN.

Obtain the IP address

If you connected the printer to your network, you will need the printer's IP address to set it up with VisitorOS.

1. While the printer is on, press and hold the Cutter button to print the set-up information.
2. On the set-up information, locate the IP address.

Next steps

Once you have obtained your IP address, you are ready to set up badge printing on VisitorOS. To learn how to set up badge printing, see Set up badge printing.
